MATLAB Implementation of Field-Oriented Control for PMSM Drive

MATLAB Implementation of Field-Oriented Control for PMSM Drive

Overview of Field-Oriented Control

  • Concept: Field-Oriented Control allows for the decoupling of torque and flux in PMSM, enabling independent control of motor speed and torque.

  • Measurement: The mechanical rotor angle is converted into electrical form, crucial for effective speed control.

Speed Control Process

  • Reference Speed: A reference speed is set, which the actual speed is compared against to determine the speed error.

  • Controller Design: A Proportional-Integral (PI) controller is typically employed to generate a reference current based on the speed error.

Current Regulation

  • IQ and ID Currents: In FOC, the current is split into two components: IQ (torque-producing current) and ID (flux-producing current). ID is maintained at zero for optimal operation.

  • Transformation: The reference currents (IA*, IB*, IC*) are generated using a transformation from dq to ABC format, essential for driving the motor effectively.

Implementation in MATLAB

  • Model Setup: A model is created incorporating a DC source, universal bridge, and PMSM, with parameters such as current and speed being measured.

  • Simulation: The simulation begins with a set reference speed, initially at 100 RPM, which is adjusted to 124 RPM after 0.05 seconds. The system's response, including current and torque, is monitored.

Results and Observations

  • Response Time: The actual speed reaches the reference command swiftly, demonstrating effective control.

  • Current and Torque Behavior: Starting currents are high, stabilizing as the motor reaches the set speed. Torque variations are observed during speed changes, reflecting the dynamic behavior of the system.

Conclusion

Field-Oriented Control for PMSM offers a robust method for achieving precise speed control in motor applications. The MATLAB implementation provides a practical approach to understanding and applying this advanced control technique.
